零回转间隙。u具有高扭转刚性、更加适应答性。u不锈钢片有较强的补偿径向、角向和轴向偏差。u顺、逆时针回转特性完全相同。u适用于伺服电机，数控铣床、机械手等机械。 单节金属膜片联轴器 结构图： 选型指导： 例：MK–b39–10/16JT MK：系列号，材料为铝合金 b39:b为夹紧型，39为外径尺寸39mm 10：d1轴径为10mm 16：d2轴径为16mm n 请参考下图参数表
MK型号d1-d2范围尺寸(mm)固定螺丝DLL1L2RM拧紧力矩MK-b26-d1/d2TT5 6 8 9.525 102625.511.5-2.5M31.5MK-b34-d1/d2TT8 9.525 10 12 12.7 143432.314.1-3.4M41.5MK-b39-d1/d2TT10 12 12.7 13 14 163934.115.0-4.6M42.5MK-b44-d1/d2TT12 12.7 14 15 16 194434.515.0-4.8M42.5MK-b56-d1/d2TT14 15 16 19 20 22 245646.020.0-5.0M57.0MK-b68-d1/d2TT18 19 22 24 28 30 356854.024.0-6.0M612.0MK-b82-d1/d2TT24 28 30 32 35 38 408268.030.0-8.0M816.0MK-b26-d1/d2JT5 6 8 9.525 102635.011.57.02.5M31.5MK-b34-d1/d2JT8 9.525 10 12 12.7 143447.014.110.63.1M41.5MK-b39-d1/d2JT10 12 12.7 13 14 163949.515.010.84.1M42.5MK-b44-d1/d2JT12 12.7 14 15 16 194450.015.011.04.5M42.5MK-b56-d1/d2JT14 15 16 19 20 22 245665.020.013.05.0M57.0MK-b68-d1/d2JT18 19 22 24 28 30 356874.024.014.06.0M612.0MK-b82-d1/d2JT24 28 30 32 35 38 408298.030.022.08.0M816.0
